High Quality Renderer Panel

This panel is where rendered images are displayed. With help of this panel you may render a scene.

Toolbar

First combobox contains list of available UV channels. Second one, allows to select image to draw behind lines.

FILE	File operations: Save rendered image or animation sequence to file. Rendered animation could be saved to video file or sequnece of images.
	Show or hide list of recently rendered images.
	Save image to file
	Copy image to clipboard
	Zoom to fit
	Actual Size
	Show red channel
	Show green channel
	Show blue channel
	Show alpha channel
	Effects: Brighthess. Contrast, Gamma.
	Start/Stop raytracing. This command renders static scene or animation. Once rendering starts, a progress bar appears in the status bar. To cancel the rendering, press Stop button.
Camera	Here you may select which viewport or view from camera should be rendered.
	Portrait/Landscape selection.
Form	Choose page form to render, including image size and resolution
	Selection of raytracer Image Format Open Raytracer configuration dialog

Thumbnails

• Click on any thumbnail to select it in the main view.
• Right click on any item to: Save to file, Copy to clipboard, Rename, Delete or clear the list.

Mouse Controls

See Also

• Floating and Docking
